The Stub Pin (Solid) – 16x50 mm is a high-precision, cylindrical alignment component widely used in jigs, fixtures, dies, and molds. Manufactured from high-grade alloy or tool steel, this pin offers exceptional strength, wear resistance, and dimensional accuracy. Its solid design provides enhanced rigidity and durability, making it ideal for repeated alignment and location purposes in high-load or high-vibration environments.
Features
- Manufactured from hardened tool or alloy steel for superior durability
- Precision ground for tight tolerances and smooth fit
- High resistance to wear, impact, and deformation
- Available with surface treatments like blackodising or zinc plating
- Easy to install and remove
- Rust-resistant options available (e.g., stainless steel)
Applications
- Tool & Die Industry – for accurate alignment in dies and molds
- Jigs & Fixtures – ensures repeatable positioning during machining or assembly
- Injection Molding – used for locating core and cavity halves precisely
- Automotive & Aerospace – alignment in high-precision components
- Machinery Assemblies – to align and secure mechanical components reliably
